-Power: Up to 2300W(or Customized)
-Speed: Up to 4000RPM(or Customized)
-Air Flow: Up to 15000m³h(or Customized)
-Speed control: Speed Controller(AC) or PWM/0-10V Input(DC&EC)
| AC Axial fan Sizes | 200mm-900mm(or Customized) |
| EC Axial fan Sizes | 200mm-800mm(or Customized) |
| DC Axial fan Sizes | 200mm-500mm(or Customized) |
| Motor Types | AC Motor |
| BLDC Motor | |
| ECM Motor | |
| Voltage | AC Motor-AC Input:115V, 220V,230V,380V,400V |
| BLDC Motor DC Input:12V,24V,48V | |
| ECM Motor AC Input:210V,220V,230V,380V | |
| Power | Up to 2300W(or Customized) |
| Speed | Up to 4000RPM(or Customized) |
| Air Flow | Up to 15000m³h(or Customized) |
| Speed control | Speed Controller(AC) or PWM/0-10V Input(DC&EC) |
| General characters | |
|---|---|
| Direction of Air Flow | All around |
| Insulation Class | Class B |
| Insulation Resistance | 50 Mega Ohm minimum at 1000VDC |
| Between frame and (+)terminal | |
| Protection Type | IP54 |
Zhongshan Pengfei Electrical specializes in customized motor solutions for industrial automation, home appliances, and new energy vehicles. ISO 9001-certified, offering end-to-end services including R&D, production, testing, and global compliance (CE, UL, RoHS). Trusted by clients worldwide.
